    Hard Insulating RF Admittance Level Transmitter Rod Type

    Ask Lasest Price
    Brand Name : nuoyingjiaye
    Model Number : NYSP-Z23
    Certification : CE
    Price : $450 to $1700
    Payment Terms : T/T
    Supply Ability : 1000 pcs/ pre month
    Delivery Time : 7 working days
    • Product Details
    • Company Profile

    Hard Insulating RF Admittance Level Transmitter Rod Type

    Hard Insulating RF Admittance Level Transmitter Rod Type


    The working principle of Admittance Level Transmitter


    Radio frequency admittance measurement technology is a level measurement technology with unique advantages. Although the concept is very similar to the general capacitive measurement technology, the RF admittance technology adds a Driving-Shield circuit and a chopper circuit in the electronic unit, so it can realize the independent measurement of impedance and capacitive reactance. It can be calculated by the laws of physics that the magnitude of the impedance and capacitive reactance of any hanging material is equal, so the effect caused by the hanging material can be measured and eliminated from the total output by the phase shift of the oscillating circuit.


    Technical Parameter of RF Admittance Level Transmitter


    ApplicationsInterface, power - off, strong mixing occasions
    Probe typeHard insulating rod
    Measuring Range0~6m
    Process temperature-40~150℃
    Ambient temperature-40 ℃ ~ + 70 ℃
    Storage temperature-20 ℃ ~ + 65 ℃
    Process pressure-0.1~2.5MPa
    Power supply(13-35)vDC
    Signal output4...20mA/HART/RS485/Modbus...
    Process connectionThread/Flange(selective)
    Protection classIP67
    Explosion-proof gradeExiaⅡCT6(selective)
    Delay:0 ~ 30 s adjustable
